PMC PH Series - Page 55

PH-20/PHX-20 Manual
55
A/R PUMP 3000 PSI - PHX-20 SIZE 61 PUMP PARTS LIST
ITEM
PART NUMBER
QTY
DESCRIPTION
1
PAX-045
1
OUTLET BODY
2
PAX-053
1
INLET BODY
3
PAX-064
1
PACKING NUT/GREASE CUP
4*
PAX-065
1
SCRAPER SEAL
5*
PAX-052
2
ROD SEAL ASSEMBLY
6
PAX-051
1
ROD BUSHING
7
PAX-062
1
FLUID ROD
8
PAX-047
1
PISTON
9
PA-063
1
BOLT
10
PAX-046
1
PISTON VALVE
11*
OR-116
1
O-RING
12
PAX-059
1
BALL ½”
13
PAX-049
1
SPRING
14
PAX-050
1
SPRING RETAINER
15
PAX-055
1
PISTON BUSHING
16*
PAX-052
1
ROD SEAL ASSEMBLY
17
PAX-058
1
INLET VALVE
18*
OR-916
1
O-RING
19
PA-048
1
BALL ¾”
20
PAX-061
1
SPRING, FOOT VALVE
21
PA-050
1
SPRING RETAINER
22
PA-056
4
CAP SCREW
23
PA-057
4
CAP SCREW
24*
OR-030
1
O-RING
25
PA-066
2
GREASE FITTING
PACKING KIT PART NUMBER
KT-PAX
*ASTERISKS DENOTES PARTS INCLUDED IN THE SEAL KIT
