PH-20/PHX-20 Manual
57
A/R PUMP 2000 PSI - PH-20 SIZE 123 PUMP PARTS LIST
ITEM
PART NUMBER
QTY
DESCRIPTION
1
PA-045
1
OUTLET BODY
2
PA-046
1
PISTON VALVE
3
PA-047
1
PISTON
4*
OR-916
1
O-RING
5
PA-048
1
BALL, 3/4”
6
PA-049
1
SPRING
7
PA-050
1
SPRING RETAINER
8
PA-051
1
ROD BUSHING
9*
PA-052
2
ROD SEAL ASSEMBLY
10
PA-053
1
INLET BODY
11*
PA-054
1
PISTON SEAL ASSEMBLY
12
PA-055
1
PISTON BUSHING
13*
OR-035
1
O-RING
14
PA-056
4
CAP SCREW
15
PA-057
4
CAP SCREW
16
PA-058
1
INLET VALVE
17
PA-059
1
BALL,1”
18 *
OR-920
1
O-RING
19
PA-060
1
BALL STOP
20
PA-061
1
FOOT VALVE SPRING
21
PA-062
1
FLUID ROD
22
PA-063
1
BOLT
23
PA-064
1
PACKING NUT/GREASE CUP
24 *
PA-065
1
SCRAPER SEAL
25
PA-066
2
GREASE FITTING
PACKING KIT PART NUMBER
KT-PA
*ASTERISKS DENOTES PARTS INCLUDED IN THE SEAL KIT
