PMC PH - Internal Component List

220 VAC – 1 Phase
9
COMPONENT LIST
ITEM
QTY
PART NUMBER
DESCRIPTION
1
1
EL-171
DIODE RECTIFIER; 1000V; 1A
2
2
EL-172
RESISTOR; 220 OHM; 5%; 3W; MET
3
1
EL-114
CIRCUIT BREAKER; 3A; 2 POLE; TYP
4
2
EL-156-10
TERMINAL COVER 10MM/5.2MM
5
1
EL-174
SS RELAY; 24 VDC
6
2
EL-152
END STOP; 35MM
7
1
EL-146
TERMINAL BLOCK; 16MM; GROUND
8
2
EL-143
TERMINAL BLOCK; 16MM
9
6
EL-141
TERMINAL BLOCK; 10.2MM
10
4
EL-188
BREAKER; 32A; 2 POLE
12
1
EL-144
TERMINAL BLOCK; 5.2MM; GRND
13
19
EL-140
TERMINAL BLOCK; 5.2MM
14
2
EL-160
SS RELAY; 24VDC; 2A
15
1
EL-119
CONTACTOR; 25A; 24VDC COIL
16
1
EL-155
RELAY SOCKET
17
1
EL-154
LATCHING RELAY; 24VDC
18
1
EL-119
CONTACTOR; 25A; 24VDC COIL
19
1
EL-122
POWER SUPPLY; 2.5A; 230VAC/24VDC
20
2
EL-34
RELAY; 50 AMP; 480V
21
1
EL-194-1
BAL CONT UNIT
23
1
EL-198
RELAY; SPDT; 24 VDC
25
1
EL-118
CONTACTOR; 32A; 24VDC
