PMC PH - Front Panel Component List (3-Phase)

220 VAC – 3 Phase
23
COMPONENT LIST
ITEM
QTY
PART NUMBER
DESCRIPTION
1
1
EL-128-W
SELECTION SWITCH; 3 POS; WHT
2
1
EL-129-G
SELECTOR SWITCH; GREEN
3
1
EL-107
E-STOP PUSH TWIST
4
1
EL-124
TOTALIZER; BATT OP
5
1
EL-127
COUNTER
7
1
EL-105
SELECTOR HANDLE; RED
8
1
EL-103
DOOR MOUNTING KIT
9
1
EL-100
ROTARY DISCONNECT; 80A; 3 POLE
10
4
EL-129-R
SELECTOR SWITCH; RED
11
2
EL-134
LIGHT HOUSING
EL-135
GREEN LENS; "ON"
12
2
EL-134
LIGHT SWITCH
EL-138
AMBER LENS; LEFT ARROW
13
1
EL-130
CODING ADAPTER
14
1
EL-128-R
SELECTOR SWITCH; 3 POS; RED
15
1
EL-159-H
TEMPERATURE CONTROLLER; HOSE
16
2
El-159-HTR
TEMPERATURE CONTROLLER; PRE-HTR
17
6
EL-131-R
LIGHT UNIT; RED; 24VDC
18
2
EL-131-W
LIGHT UNIT; WHITE 24VDC
19
2
EL-131-G
LIGHT UNIT; GRN; 24VDC
20
1
EL-132-G
GREEN LIGHT UNIT
21
3
EL-133-NC
CONTACT BLOCK; NC
22
11
EL-133-NO
CONTACT BLOCK; NO
27
1
EL-196
ROTARY SWITCH 7 POS
28
1
EL-134
LIGHT HOUSING
EL-137-F
RED LENS; "FAULT"
29
1
EL-197
ROTARY SWITCH KNOB
