CR Family Hardware Installation Guide Page 10 of 30
Copyright © 2016 by Pointer Telocation, Ltd.
The harness is made up of colored 22AWG wires, 1.2 meters long, utilizing a 10-pin
connector that links to the CR unit and a 4 pin connector for the serial interface. A fuse
holder with 3A fuse and PTC Resettable Fuse 60V and Imax=40A is attached to the
harness.
The following table provides a description of the harness. Additional information can be
found in the relevant sections dealing with the harness installation instructions.
Table 2: CR 10 Wires Harnesses description
Wire
Number
Name
Wire
Color
CR Unit
Pin
Number
Function
W1
Main Power
Red
1
Main Power
W2
GND
Black
6
Ground
W3
Ignition
Violet
4
Ignition
W4
SHOCK
Yellow
9
General Purpose Input
W5
LED
Green
2
General Purpose
output or LED
W6
Global Output
Brown
3
General Purpose
output.
W8
DOOR
Pink
5
General Purpose
output.
W9
DALLAS
Grey
10
1-Wire interface
P2(2)
TX
7
Serial TX
P2(3)
RX
8
Serial RX
