CR Family Hardware
Installation Guide
CR Family Hardware Installation Guide Page 22 of 30
Copyright © 2016 by Pointer Telocation, Ltd.
2. Gently slide t h e SIM card into the SIM holder as shown below.
Figure 15: Inserting the SIM Card
3. Close the unit, insert the 2 screws and tighten to a torque of 3.5 kgf-cm (kilogram
force per centimeter) which is approximately 0.35 Nm (Newton per Meter).
4.5 Installing the Battery in CR B Models
See Battery Handling Procedure for Cellocator Units for information about the battery and
its handling instructions.
If you received the device without the battery or you received the device with the battery
inside but not connected, please open the device, connect the battery cable to the on-
board connector and close the device. When you connect the vehicle battery to the
device, the device will start working normally. Do not reverse the order of connections;
the correct order is to first connect the battery then connect the vehicle power to the
device.
