CR Family Hardware Installation Guide Page 6 of 30
Copyright © 2016 by Pointer Telocation, Ltd.
2 CR Family Overview
2.1 Introducing the Main Elements of the CR Family Unit
Figure 1 below shows the main elements of a CR unit.
Figure 1: Main Elements of a CR unit
Figure 2 provides an internal view of the CR unit and all relevant elements.
Connector
aANTEANTE
NA
GPS Module
aANTEANTENA
SIM Holder
Processor
GSM antenna
aANTEANTENA
Screw
GSM antenna
aANTEANTENA
GPS Antenna
aANTEANTENA
GSM Modem
aANTEANTENA
Connector
aANTEANTE
NA
Preparation for Ties
