CR Family Hardware
Installation Guide
CR Family Hardware Installation Guide Page 14 of 30
Copyright © 2016 by Pointer Telocation, Ltd.
Isolate the connection with a plastic cover or a professional insulation tape so that no
wires remain exposed.
Figure 6: Isolate the Connection
Use existing wire ducts, openings and holes to pass wires between different areas in
the vehicle. Do not punch or drill new openings or holes to pass wires between
different zones in the vehicles, as this will create permanent damage to the vehicle,
and other wires or pipes. Make sure the opening is properly protected by a grommet
or a plastic sleeve to prevent damage to the wires.
Figure 7: Preventing damage to the wires
