5.1.3.2 GPS Monitoring Zone Definition
5.1.4 Global Output
The harness Global Output brown wire is connected to the CR Pin no. 3.
The output functionality is defined according to programming parameters (PL). In most
cases, the CR unit uses this output as a global output, allowing activation/deactivation of
several devices, such as blinkers, parking lights, an additional siren, etc. In this case the
output shall be connected to the required device as shown in the following installation
diagram.
