CR Family Hardware
Installation Guide
CR Family Hardware Installation Guide Page 8 of 30
Copyright © 2016 by Pointer Telocation, Ltd.
-------------------------------------------------------------------------------------------
IMPORTANT:
The CR unit must be protected by means of a 3A fast blow fuse. The fuse should be
installed either between Power Input (Pin 1) and the vehicle protected power line.
The CR unit must be protected by means of PTC for safety certification compliance.
The PTC should support Resettable Fuse 60V and Imax=40A. It should be installed
between Power Input (Pin 1) and the vehicle protected power line.
These means of protections are supported by the by the fuse attached to the
harnesses provided by Cellocator.
It is the installer responsibility to provide these means of protection if the fuse
provided by Cellocator is not used.
-------------------------------------------------------------------------------------------
