ENGINE
2.8
ENGINE DISASSEMBLY, CONT.
20. Remove belt.
21. Remove primary clutch sheave.
22. Remove the nut on driven clutch and remove clutch
assembly.
NOTE:Be careful not to lose the oil ring upon removal.
Starter Clutch Set
23. Remove idle gear bolts.
24. Remove the plate, shaft pin, washers, and idle gear.
