BODY / STEERING / SUSPENSION
4.7
STEERING
1. Grease the steering post sleeve and insert in
place. Mount the steering post clamps on post.
Install the steering post and tighten the steering
post mount nuts to specification.
Steering Post Mount Nut Torque:
103 in.lbs. (11.6 Nm)
Steering Post
Steering Post Bushings
Left Tie Rod Asm.
Right Tie Rod Asm.
Steering Post Sleeve
Seal
Circlip
Bearing
Seal
Spacer
Washer
Nut
To Next Page
