ENGINE
2.24
ENGINE ASSEMBLY
25. Make sure cylinder is clean and free of debris.
Install cylinder carefully making sure the piston
rings are in the correct position.
26. Install a new head gasket and install head. Torque the
cylinder head in a criss-cross patten to specification.
27. Install new spark plug. Spark plug gap should be
.024-.028″ (.6-.7 mm).
28. Install intake manifold and reed valve. Install bolts
securing the intake manifold. Torque to specification.
NOTE:Remove any remaining gasket material from the
reed valve housing and crankcase. Always replace the
reed valve gasket when removing.
NOTE:Check the condition of the reed. If petals look
damaged in any way, replace.
Cylinder Head Nut Torque:
14 ft.lbs. (19 Nm)
Spark Plug Gap:
024-.028I (.6-.7 mm)
Intake Manifold Bolt Torque:
108 in.lbs. (12 Nm)
