BODY / STEERING / SUSPENSION
4.1
TORQUE SPECIFICATIONS
Front A-Arm Attaching Bolt 26-30 ft. lbs. (36-40 Nm). . . . . . . . . . . . . . . . . .
Handlebar Adjuster Block 84 in. lbs. (10 Nm). . . . . . . . . . . . . . . . . . .
Rear Shock Bolts 25 ft. lbs. (35 Nm). . . . . . . . . . . . . . . . . . . . . . . . . . .
Rear Wheel Hub Nut 78-81 ft. lbs. (108-112 Nm). . . . . . . . . . . . . . . . . . . . . . .
Front Shock Bolts 15 ft. lbs. (20 Nm). . . . . . . . . . . . . . . . . . . . . . . . . .
Swing Arm Mounting Bolt 26-30 ft. lbs. (36-40 Nm). . . . . . . . . . . . . . . . . . . .
Inner Tie Rod Bolts 33-40 ft. lbs. (45-55 Nm). . . . . . . . . . . . . . . . . . . . . . . . .
Outer Tie Rod Bolts 33-40 ft. lbs. (45-55 Nm). . . . . . . . . . . . . . . . . . . . . . . .
Tie Rod Jam Nuts 12-14 ft. lbs (17-19 Nm). . . . . . . . . . . . . . . . . . . . . . . . . .
Motor Mount Bolts-M8 22-25 ft. lbs (30-35 Nm). . . . . . . . . . . . . . . . . . . . . .
Motor Mount Bolts-M10 33-40 ft. lbs (45-55 Nm). . . . . . . . . . . . . . . . . . . . .
Spindle Nuts 40-45 ft. lbs (58-62 Nm). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Steering Post Mount Nuts 103 in. lbs (11.6 Nm). . . . . . . . . . . . . . . . . . .
Steering Post Nut 62-65 ft. lbs (86-90 Nm). . . . . . . . . . . . . . . . . . . . . . . . . .
Steering Nuts 62-65 ft. lbs (86-90 Nm). . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Sprocket Bolts 18 ft. lbs (25 Nm). . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chain Tensioner Bolt 84 in. lbs (10 Nm). . . . . . . . . . . . . . . . . . . . . . . .
Bearing Carrier Mounting Bolts 43 ft. lbs (60 Nm). . . . . . . . . . . . . . .
Rear Cover Mounting Bolts 84 in. lbs (10 Nm). . . . . . . . . . . . . . . . . .
Fuel Tank Mounting Bolts 103 in. lbs (12 Nm). . . . . . . . . . . . . . . . . . . .
Oil Tank Mounting Bolts 103 In. lbs (12 Nm). . . . . . . . . . . . . . . . . . . . .
Front Bumper Mounting Bolts 103 in. lbs (12 Nm). . . . . . . . . . . . . . . .
Cab Mounting Bolts 103 in. lbs (12 Nm). . . . . . . . . . . . . . . . . . . . . . . . .
Muffler Mounting Bolts 25 ft. lbs (34 Nm). . . . . . . . . . . . . . . . . . . . . .
NOTE: Refer to exploded views throughout this chapter for identification and location of components.
SPECIAL TOOLS
Description Part No.
Shock Spanner Wrench 2870872. . . . . . . . . . . . . .
Shock Spring Compressor Tool 2870623. . . . . . .
