BODY / STEERING / SUSPENSION
4.4
ENGINE MOUNTING
1. Install rubber dampers under footrest and install
footrest on frame body.
2. Tighten footrest bolts.
3. There are three (3) engine mounting positions on
the frame. Check each bushing of the engine
brackets for damage or wear before mounting the
engine to the frame body.
4. Insert the engine into the frame body. Mount to the
brackets including the fix tube, spacer tube, and
engine holder seat.
1
2
3
Motor Mount Bolt Torque:
M10= 33-40 ft.lbs. (45-55 Nm)
M8= 22-25 ft.lbs. (30-35 Nm)
