Polaris 3500 User Manual

-4-
INSTALLATION INSTRUCTIONS
1. Place the vehicle in “PARK” and turn the key to
“OFF” position. Remove the key from the vehicle.
Remove the driver seat. Disconnect the black
negative and the red positive battery cable from the
battery. Figure 1.
2. Remove the hood from the vehicle by twisting the
two knobs and pulling up. Figure 2.
3. Remove the shift lever cap by using a at
screwdriver to remove the cap of the shift handle.
Remove the handle screw with a T25 Torx bit
retaining it for reuse and pull up to remove the
handle from the shift lever weldment. Figure 3.
Figure 1
Battery Cables
Under Seat
Figure 2
Figure 3
Knob
Cap
Shift
Housing
Pull
Pull
