Polaris 700 Fusion 2006 User Manual

1.7
SPECIFICATIONS
Table 1-32: Fluids and capacities
Fuel gal/l 11.8/44.7
Oil qts/l 3.25/3.1
Coolant qts/l N/A
Chaincase oz/ml 9/266.2
Brake fluid type DOT4
Table 1-33: Track
Width in/cm 15/38
Length in/cm 121/307
Lug height in/cm .82/2.1
Track tension sag in/cm with
10 lbs/4.54kg placed 16 in/
40.6cm ahead of rear idler
shaft
.375-.5/1-1.3
Table 1-34: Front Suspension
Suspension type
Edge
IFS shocks Arvin/7041932
IFS spring rate
lbs-in/kg-mm
100/1.79
IFS spring installed length
in/cm
9.81/24.9
Front vertical travel in/cm 10/25.4
Ski center distance in/cm 42.5/108
Camber in/mm .59±.31/15.0±7.9
Toe in/mm .12-.25/3.0-6.35
Table 1-35: Rear Suspension
Suspension type Edge
Front track shock (FTS) Arvin/7041939
FTS Spring rate
lbs-in/kg-mm
100/1.79
FTS Installed length Fixed
Rear track shock Fox/7042129*
Rear travel in/cm 13.9/35.3
* notes that shock is rebuildable
Table 1-36: Torsion spring
Torsion spring PNs
(LH/RH)
7041629/7041630
Torsion spring diameter in/mm .359/9.12
Torsion spring tail angle 77_
Table 1-37: Dimensions
Width in/cm 48/122
Length in/cm 113/287
Height in/cm 48/122
Est dry weight lb/kg 489/222
Table 1-38: Electrical
Ignition timing
27_@3000
14_@6500
Spark plug gap in/mm .028/.71
Spark plug NGK BR9ES
Voltage regulator/output 240watt
Magneto pulse 6
CDI marking CU7242
