SPECIFICATIONS
600 CLASSIC
MODEL S06ND6ES
Table 1-39: Engine
Engine type Liberty
Engine displacement 599
Bore in/mm 3.04/77.25
Stroke in/mm 2.52/64
Piston to cylinder clearance in/
mm
.0045-.0059/.115-.149
Piston ring end gap .014-.020/.0356-.508
Operating RPM±200 8100
Idle RPM 1200
Clutch engagement RPM ±200 4000
Exhaust valve spring Green/Yellow
Table 1-40: Fuel Delivery
Type TM38
Main Jet 440
Pilot Jet 45
Jet Needle/Clip position 9DFH7-60/3
Needle Jet P-8
Throttle gap under cutaway
in/mm
.079/2
Throttle slide cutaway 2.5
Valve seat 1.5
Starter jet 140
Pilot air jet N/A
Fuel screw setting 2.5
Air screw setting 1
Recommended fuel octane
(R+M/2)
87 Min. NonOxy
Table 1-41: Jetting
Altitude
meters
(feet)
Ambient Temperature
< -25_F/<-35_C
-30_F to -10_F/-34_C to -23_C
-15_F to +5_F/-26_C to -15_C
0_F to +20_F/-18_C to -7_C
+15_F to +35_F/-9_C to +2_C
+30_F to +50_F/-1_C to +10_C
+45_F to +65_F/+7_C to +18_C
>+60_F/>+16_C
0-600
(0-2000)
480
#4
460
#4
440
#3
430
#3
420
#3
400
#3
390
#2
380
#2
600-1200
(2000-4000)
450
#4
430
#4
420
#4
410
#3
400
#3
380
#2
360
#2
350
#2
1200-1800
(4000-6000)
420
#4
400
#4
390
#3
380
#3
370
#2
350
#2
330
#2
320
#2
1800-2400
(6000-8000)
400
#4
380
#3
360
#2
350
#2
340
#2
330
#2
310
#2
300
#2
2400-3000
(8000-10000)
370
#3
350
#2
340
#2
330
#2
320
#2
300
#2
280
#2
370
#2
3000-3700
(10000-12000)
340
#2
330
#2
310
#2
300
#2
290
#2
270
#1
260
#1
250
#1
When using non oxygenated fuel with a research octane
Number (RON) of greater than 93, decrease the main jet
number on the above chart by 30.
Table 1-42: Clutching
Altitude meters
(feet)
Drive Clutch (P-85) Driven Clutch (TEAM)
Shift
Weight
Clutch
Spring
Clutch
Spring
Driven
Helix
Gearing
0-900
(0-3000)
10-58
Dark
Blue/
White
Red/Blue
58/42-36
ER
23:39-74
900-1800
(3000-6000)
10-56
Dark
Blue/
White
Red/Blue
58/42-36
ER
23:39-74
1800-2700
(6000-9000)
10-54
Dark
Blue/
White
Red/Blue
58/42-36
ER
23:39-74
2700-3700
(9000-12000)
10
Dark
Blue/
White
Red/Blue
58/42-36
ER
22:39-74
Drive clutch bolt torque 50 ft-lbs(69Nm)
Table 1-43: Belt
Belt part number 3211080
Belt width in/cm 1.438/3.65
Belt side angle 28_
Outside diameter in/cm 46.625/118.4
Clutch center distance in/cm 11.5/29.2
