Polaris 700 Fusion 2006 User Manual

1.9
SPECIFICATIONS
Table 1-44: Chaincase
Center distance in/cm 7.92/20.1
Reverse type PERC
Table 1-45: Fluids and capacities
Fuel gal/l 11.8/44.7
Oil qts/l 3.25/3.1
Coolant qts/l 5.6/5.3
Chaincase oz/ml 9/266.2
Brake fluid type DOT4
Table 1-46: Track
Width in/cm 15/38
Length in/cm 121/307
Lug height in/cm 1/2.5
Track tension sag in/cm with
10 lbs/4.54kg placed 16 in/
40.6cm ahead of rear idler
shaft
.875-1.13/2.2-2.9
Table 1-47: Front Suspension
Suspension type Edge
IFS shocks Arvin/7041918
IFS spring rate
lbs-in/kg-mm
90-180/1.6-3.2
IFS Spring installed length
in/cm
9.5/24.1
Front vertical travel in/cm 10.25.4
Ski center distance in/cm 42.5/108
Camber in/mm .59±.31/15.0±7.9
Toe in/mm .12-.25/3.0-6.35
Table 1-48: Rear Suspension
Suspension type Edge M-10
Front track shock (FTS) Fox/7042224*
FTS spring rate in-lbs/kg-
mm
160/2.86
FTS pre-load in/mm .90/23
Rear track shock (RTS) Fox/7042216*
RTS Springs 7041935-7041936
RTS Spring Rate
lbs-in/kg-mm
185 VAR-1000/3.3-17.9
RTS spring installed length
in/cm
10.5/25.4
Rear travel in/cm 14/35.6
* notes that shock is rebuildable
Table 1-49: Dimensions
Width in/cm 47.25/120
Length in/cm 113/287
Height in/cm 48/122
Est dry weight lb/kg 497/255.6
Table 1-50: Electrical
Ignition timing 24_@3500RPM
Spark plug gap in/mm .025/.64
Spark plug Champion RN57YCC
Voltage regulator/output 280watt
Magneto pulse 6
CDI marking 4010830
