DIAGNOSTIC TROUBLE CODES (DTCS) – MATRYX
SPN = SUSPECT PARAMETER NUMBER / FMI = FAILURE MODE INDICATOR
TROUBLE CODE SPN FMI P-CODE CONDITION
Fuel Rail Pressure Below Power
Limit
157 18 P0196 This Trouble Code Sets if the Fuel Pressure drops below 3Bar
(43.5PSI) for 10 seconds. Can be caused by a faulty Pump Flange
Assembly (PFA).
Battery Voltage High 158 3 P1567 This Trouble Code Sets if the if the Battery Voltage is above 15.0V. Can
be caused by Damaged Wiring, a faulty Battery or ECU / Connections.
Battery Voltage Low 158 4 P1566 This Trouble Code Sets if the if the Battery Voltage is below 10.0V. Can
be caused by Damaged Wiring, a faulty Battery or ECU / Connections.
Exhaust Over-Temperature
Shutdown
173 0 P1517 This Trouble Code Sets if the engine was shut down due to High
Exhaust Temperature. Can be caused by a Faulty Exhaust Temperature
Sensor/Connections or Lean Air/Fuel Ratio causing high exhaust
temperature.
Exhaust Temp Sensor Signal High 173 3 P0546 This Trouble Code sets if the engine has been running above 3000
RPM for more than 2 minutes and the Exhaust Temperature Sensor
Signal is above 4.90 Volts. Can be caused by Damaged Wiring, a faulty
Engine Temperature Sensor or ECU / Connections.
Exhaust Temp Sensor Signal Low 173 4 P0545 This Trouble Code sets if the engine has been running above 3000
RPM for more than 2 minutes and the Exhaust Temperature Sensor
Signal is below 0.06 Volts. Can be caused by Damaged Wiring, a faulty
Engine Temperature Sensor or ECU / Connections.
Exhaust Temp Sensor Unrealistic
Transition
173 10 P1546 This Trouble Code sets if the Exhaust Temperature Sensor Signal
changes too quickly to be considered a Realistic Value. Can be caused
by Damaged Wiring, a faulty Exhaust Temperature Sensor or ECU /
Connections.
Fuel Temperature Sensor Voltage
High
174 3 P1322 This trouble code sets if the Fuel Temperature Sensor Voltage is above
4.81V. Can be caused by Damaged Wiring, a faulty Fuel Pressure
Sensor or ECU / Connections.
Fuel Temperature Sensor Voltage
Low
174 4 P1323 This trouble code sets if the Fuel Temperature Sensor Voltage is Below
0.01V. Can be caused by Damaged Wiring, a faulty Fuel Pressure
Sensor or ECU / Connections.
ECU Memory Checksum Error 628 13 P0601 This Trouble Code Sets if an Internal Memory Fault is detected in the
Engine Controller. Can only be caused by a defective ECU.
Crankshaft Sensor Signal Fault 636 2 P0335 This Trouble Code sets if the Engine is Running and No Signal is
Detected from the 5X Crankshaft Sensor. Can be caused by Damaged
Wiring, a faulty Crankshaft Sensor or ECU / Connections.
Crankshaft Position Sensor Circuit
Fault
636 8 P0336 This Trouble Code sets if the Engine is Running and the number of
pulses from the 5X Crankshaft Sensor is not correct. Can be caused by
Damaged Wiring, a faulty Crankshaft Sensor or ECU / Connections.
MAG Cylinder Port Injector Short
to B+
651 3 P0262 This Trouble Code sets if a Short to Voltage is detected in the MAG
Cylinder Port Injector Control Circuit. Can be caused by Damaged
Wiring, a faulty Fuel Injector or ECU / Connections.
MAG Cylinder Port Injector Open
Circuit
651 5 P0261 This Trouble Code sets if an Open Circuit Condition is detected in the
MAG Cylinder Port Injector Control Circuit. Can be caused by Damaged
Wiring, a faulty Fuel Injector or ECU / Connections.
PTO Cylinder Port Injector Short
to B+
652 3 P0265 This Trouble Code sets if a short to Voltage is detected in the PTO
Cylinder Port Injector Control Circuit. Can be caused by Damaged
Wiring, a faulty Fuel Injector or ECU / Connections.
PTO Cylinder Port Injector Open
Circuit
652 5 P0264 This Trouble Code sets if an Open Circuit Condition is detected in the
PTO Cylinder Port Injector Control Circuit. Can be caused by Damaged
Wiring, a faulty Fuel Injector or ECU / Connections.
Ignition Coil 1 (MAG) Driver Circuit
Open
1268 5 P1351 This Trouble Code Sets if Ignition Coil 1 (MAG) Driver Circuit is Open.
Can be caused by Damaged Wiring/Connections, a Faulty MAG Ignition
Coil or ECU.
Ignition Coil 2 (PTO) Driver Circuit
Open
1269 5 P1352 This Trouble Code Sets if Ignition Coil 2 (PTO) Driver Circuit is Open.
Can be caused by Damaged Wiring/Connections, a Faulty PTO Ignition
Coil or ECU.
