9850064 R03 - 2021 650 / 850 Matryx Trail Performance / Crossover Snowmobile Service Manual
© Copyright Polaris Inc.
8.89
REF. DESCRIPTION
TORQUE / NOTE
q
Shaft Loop 18 ft-lbs (24 N·m)
w
Shock Shaft
e
Reservoir Body 10 ft-lbs (14 N·m)
r
IFP Piston Assembly
t
Spring Adjuster
y
Lock Nut
15 ft-lbs (20 N·m)
u
O-Ring Replace with new when removed.
i
Seal Head Assembly
45 ft-lbs (61 N·m)
Replace seal head assembly if shaft bushing is damaged / worn.
o
Shock Body
a
Jounce Bumper
s
Spring Retainer
d
Body Cap 45 ft-lbs (61 N·m)
f
Adjuster Assembly
25 ft-lbs (34 N·m)
Adjuster Assembly Nut - 45 in-lbs (5 N·m)
g
Sticker
h
Piston Seal Spacer
j
End Cap / Service Port Replace service port assembly after fifth charging.
k
Snap Ring
l
Sleeve
1(
Bushing
2)
Piston Assembly
2!
O-Ring Replace with new when removed.
2@
Jam Nut
— Spring
Not shown.
