8
9850064 R03 - 2021 650 / 850 Matryx Trail Performance / Crossover Snowmobile Service Manual
© Copyright Polaris Inc.
8.93
19.To service the reservoir, remove the tube from the
body cap. Discard the O-ring.
20.The clicker knob can be serviced by removing the
screw and knob.
21.Optional service: Remove the clicker assembly from
the body cap.
NOTICE
Servicing the clicker assembly is difficult without the
proper tools.
22.Optional service: Remove the spacer and O-ring
from the clicker assembly.
23.Optional service: Disassemble the clicker assembly
as shown. Discard all O-rings and replace with new.
NOTICE
Clicker compression washers may differ from shock to
shock. See specification tables for washer settings.
24.Optional service: To service the shock body, remove
the shock body from the body cap. Discard the O-
ring.
STEERING / SUSPENSIONS
