9850064 R03 - 2021 650 / 850 Matryx Trail Performance / Crossover Snowmobile Service Manual
© Copyright Polaris Inc.
8.101
REF. DESCRIPTION
TORQUE / NOTE
q
Shaft Loop 18 ft-lbs (24 N·m)
w
Retainer Spring Nut
e
Sleeve
r
Bushing
t
Shock Shaft
y
End Bearing
u
Snap Ring
i
Jounce Bumper
o
Shock Body
a
Shock Bridge
s
Reservoir Body 10 ft-lbs (14 N·m)
d
End Cap / Service Port Replace service port assembly after fifth charging.
f
IFP Piston Assembly
g
Adjuster Assembly
25 ft-lbs (34 N·m)
Adjuster Assembly Nut - 45 in-lbs (5 N·m)
h
Seal Head Assembly
45 ft-lbs (61 N·m)
Replace seal head assembly if shaft bushing is damaged / worn.
j
Snap Ring
k
O-Ring Replace with new when removed.
l
Spring Retainer
1(
Piston Assembly
2)
Lock Nut
15 ft-lbs (20 N·m)
2!
Jam Nut
2@
O-Ring Replace with new when removed.
2#
Retaining Ring
2$
Wear Band. Spring Guide
— Spring
Not shown.
