SCHEMATIC CABLE/WIRE TERMINATION TABLE
INDEX CCT # TYPE GAUGE COLOR FROM COMPONENT FROM PORT TO COMPONENT TO PORT FUNCTION
1 BUSA_3_5 BUS BUS BUS LOAD CENTER A3 LOAD CENTER A5 CHASSIS LOAD CENTER BUS
2 BUSA_5_7 BUS BUS BUS LOAD CENTER A5 LOAD CENTER A7 CHASSIS LOAD CENTER BUS
3 BUSB_5_7 BUS BUS BUS LOAD CENTER B5 LOAD CENTER B7 EV LEARN LOAD CENTER BUS
4 BUSB_7_9 BUS BUS BUS LOAD CENTER B7 LOAD CENTER B9 EV LEARN LOAD CENTER BUS
5 CONST01 TXL (SBBC) 0.5 PK/WH CONSTANT PWR SPLICE 2 IGNITION SWITCH D CONSTANT PWR
6 CONST02 TXL 0.5 PK/BK CONSTANT PWR SPLICE 2 HOOD/CHASSIS 3 CONSTANT PWR
7 DBATT01 TXL 0.5 PK/WH LOAD CENTER D2 CONSTANT PWR SPLICE 1 BATTERY DIODE PWR
8 DCR01 TXL 0.5 RD/BN LOAD CENTER C2 CONSTANT PWR SPLICE 1 CRITICAL DIODE PWR
9 EA23 TXL 0.5 RD/WH SPLICE,CHASSIS POWER #1 1 ECU_CNA 23 CHASSIS PWR
10 EA24 TXL 0.5 PK/BK LOAD CENTER D3 ECU_CNA 24 BATTERY VOLTAGE
11 LED01 TXL 0.5 WH/RD ACCENT LED-HANDGUARD A HOOD/CHASSIS 10 ACCENT LED - HANDGUARDS
12 LED03 TXL 0.8 VT/YE FRONT WORK LIGHT SWITCH B FRONT WORK LIGHT 1 WORK LIGHT PWR
13 LHC01 TXL 0.5 DB LEFT HAND CONTROLS 6 HANDLEBAR CONNECTION 5 RH HEATER PWR
14 LHC02 TXL 0.5 DB/RD LEFT HAND CONTROLS 7 HANDLEBAR CONNECTION 1 LH HEATER
15 LHC03 TXL 0.5 GY/OG LEFT HAND CONTROLS 8 HANDLEBAR CONNECTION 7 THUMBWARMER PWR
16 PBATT03 TXL 0.8 PK/BK ELECTRIC START 8 LOAD CENTER D3 FUSED BATTERY PWR
17 PCH01 TXL 2.0 RD/WH PBR (DC POWER) P1 SPLICE,CHASSIS POWER #1 2 CHASSIS PWR
18 PCH02 TXL 2.0 RD/WH SPLICE,CHASSIS POWER #1 2 LOAD CENTER A3 CHASSIS PWR
19 PCH03 TXL 1.0 RD/WH SPLICE,CHASSIS POWER #1 1 DIAGNOSTIC POWER D CHASSIS PWR
20 PCH04 TXL 2.0 RD/WH SPLICE,CHASSIS POWER #1 1 LOAD CENTER C4 CHASSIS PWR
21 PCH05 TXL 0.8 RD/BU LOAD CENTER A2 REAR HARNESS D FUSED PASSENGER PWR
22 PCH06 TXL 1.0 RD/WH LOAD CENTER A4 SPLICE,ACCESSORY POWER 2 ACC FUSED PWR
23 PCH06-1 TXL 0.8 RD/WH SPLICE,ACCESSORY POWER 1 DRIVER SEAT HEATER SWITCH A ACC FUSED PWR
24 PCH06-2 TXL 0.8 RD/WH RCA ACCESSORY POWER A SPLICE,ACCESSORY POWER 1 ACC FUSED PWR
25 PCH06-3 TXL 0.8 RD/WH SPLICE,ACCESSORY POWER 1 HOOD/CHASSIS 9 ACC FUSED PWR
26 PCH06-4 TXL 0.8 RD/WH SPLICE,ACCESSORY POWER 2 FRONT WORK LIGHT SWITCH A ACC FUSED PWR
27 PCH06-5 TXL 0.8 RD/WH SPLICE,ACCESSORY POWER 2 VCM 2 ACC FUSED PWR
28 PCH12-1 TXL 0.8 RD/WH LOAD CENTER A6 LEFT HAND CONTROLS 2 FUSED DRIVER CHASSIS PWR
29 PCH30 TXL 2.0 RD/YE LOAD CENTER D5 BATT CHARGE SPLICE 2 CHASSIS PWR
30 PCH30-1 TXL 1.0 RD/YE BATT CHARGE SPLICE 1 ELECTRIC START 7 BATTERY CHARGING
31 PCH30-2 TXL 1.0 RD/YE BATT CHARGE SPLICE 1 ELECTRIC START 6 BATTERY CHARGING
32 PCH30-3 TXL 1.0 RD/YE BATT CHARGE SPLICE 1 ELECTRIC START 5 BATTERY CHARGING
33 PCH31 TXL 0.8 GY/OG DRIVER SEAT HEATER SWITCH B REAR HARNESS E DRIVER SEAT HI
34 PCH32 TXL 0.8 GY DRIVER SEAT HEATER SWITCH C REAR HARNESS F DRIVER SEAT LOW
35 PCR03-1 TXL 0.5 RD LOAD CENTER C8 LOAD CENTER D8 CRITICAL PWR
36 PCR03-2 TXL 0.5 RD LOAD CENTER D4 LOAD CENTER D8 CRITICAL PWR
37 PCR10 TXL 0.8 RD/BK LOAD CENTER D9 LOAD CENTER B9 BRAKE LIGHT PWR
38 PCR14 TXL 0.8 RD/BK LOAD CENTER C3 LOAD CENTER B4 FUSED GAUGE PWR
39 SWPWR01 TXL (SBBC) 0.5 RD/BN IGNITION SWITCH C SWITCHED POWER SPLICE 1
SWITCHED PWR
40 SWPWR01-1 TXL 0.5 RD/DG SWITCHED POWER SPLICE 2 LEFT HAND CONTROLS 11 SWITCHED PWR
41 SWPWR01-2 TXL 0.5 RD/DG SWITCHED POWER SPLICE 2 HOOD/CHASSIS 2 SWITCHED PWR
09/25/20
1
2
3
A
B
C
D
E
F
G
H
I
4
5
6
789
10
WIRE COLOR LEGEND
BG
BK
BU
DB
BN
GY
GN
DG
OG
PK
RD
VT
WH
YE
BEIGE (TAN)
BLACK
LIGHT BLUE
DARK BLUE
BROWN
GRAY
LIGHT GREEN
DARK GREEN
ORANGE
PINK
RED
VIOLET (PURPLE)
WHITE
YELLOW
TWO WIRE COLORS ARE SHOWN
WITH MAIN/TRACE COLORS.
EXAMPLE:RD/YE = RED WITH
YELLOW TRACE.
CHASSIS POWER CIRCUIT
E = ENGINE GROUND
C = CHASSIS GROUND
NC = SWITCH NORMALLY CLOSED
NO = SWITCH NORMALLY OPEN
HARNESS: 2415122_650_850_CHAS-01
SHEET NO. 2 OF 2
DRAWN: 30-APR-20
