108
MAINTENANCE
PTO Drive Belt (If Applicable)
Belt Inspection
Check the PTO drive belt at the correct service interval as out-
lined in the Periodic Maintenance Chart beginning on page 78.
The PTO drive belt has a constant tension idler to keep the cor-
rect tension on the belt.
Stop the machine on a flat level surface. Put the gear selector
in Park, stop the engine and exit the vehicle. See page 41.
Raise the cargo box. See page 62.
The drive belt idler (Item 1)
is under constant spring load
to keep the belt at the correct
tension. No adjustment can
be made. If belt slippage is
noticed, the belt and / or the
constant tension pulley must
be replaced. Inspect belt con-
dition. If belt wear, including
the side of the belt is visible,
belt replacement is needed.
See your dealer for service).
Tip: If the PTO belt needs replacement, the bell housing and hydro-
static pump removal is required. See your dealer for service.
