115
MAINTENANCE
Fuses
If the engine stops or will not start, or if you experience other
electrical failures, a fuse or relay may need replacement.
Locate and correct any short circuits that may have caused a
blown fuse, then replace the fuse. Spare fuses are provided in
the fuse box.
If you suspect that a fuse or relay may not be working prop-
erly, please see your POLARIS dealer.
The fuse panel is located below the seat between the operator
and passenger. For the BRUTUS model, remove the seat. For
HD and HD
PTO models, the center console will need to be
removed.
Additional relays and fuses are
also located in the same area as
the fuse and relay panels.
1. Relay = Radiator fan motor
2. Relay = HVAC (if
equipped)
3. In-line fuse (30A) = HVAC
(if equipped)
4. Circuit Breaker (40A) =
Radiator fan motor
5. Circuit Breaker (20A) = Condenser fan motor (if
equipped)
