101
MAINTENANCE
Air Conditioning (if equipped)
Belt Adjustment
5. If the belt tension is not correct, loosen the
mounting bolt and adjustment bolt.
6. Move the top of the compressor to tighten the belt.
7. Tighten the mounting bolt to 15 ft-lbs (20 Nm).
8. Tighten the adjustment bolt to 28 ft-lbs (38 Nm).
9. Install the shield and three bolts.
10. Lower the cargo box. See page 57.
Belt Replacement
1. Loosen the mounting and adjustment bolts and
move the compressor toward the engine.
2. Remove the belt.
3. Install the new belt and adjust as shown under Belt Adjustment.
Filter Cleaning
The air conditioning filter is located below the dash.
1. Remove the two fasteners and remove the filter
cover.
2. Clean the filter with low air pressure. Check for
damage, replace if damaged.
