48
OPERATION
Attachments (Models HD and HDPTO)
Installing And Removing Attachments
Removing
Tip: In muddy conditions or to prevent the attachment from freezing to the ground, put the attachment
on planks or blocks before removing the attachment from the vehicle.
1. Lower the attachment arm and put the attachment
flat on the ground.
2. Move the gear selector lever to PARK and stop the
engine. See page 40.
3. If the attachment is hydraulically controlled, (snow
blade, etc.), relieve the hydraulic pressure at the
quick couplers. See page 44.
4. Disconnect the auxiliary hydraulic quick couplers.
(if equipped). See page 44.
5. Disconnect the PTO driveline (if equipped). See
page 45.
6. Remove the two retainers and pins (both side).
7. Install the two pins and retainers into the storage
position.
8. Start the engine. See page 39. Move the gear
selector lever to LOW.
9. Be sure the attachment is fully lowered and the
attachment is flat on the ground.
10. Tilt the attachment interface forward. Move
backward, away from the attachment.
WARNING! Avoid injury or death. Before you leave the
operators seat:
• Park on flat level ground.
• Lower the attachment arm, put the attachment flat on the
ground.
• Press the brake pedal and move the gear selector lever to
PARK.
• Disengage the PTO (if equipped) and make sure all
rotating components are completely stopped.
• Stop the engine and remove the key.
