66
ATTACHMENT ARM
Removing And Installing (Models HD and HDPTO)
The PRO-TACH attachment system is used for fast changing of buckets and other
attachments. See the appropriate attachment Owner’s Manual to install other attachments.
11. Rotate the tilt cylinder up and into the storage position. A heavy tie strap can be used to
secure the cylinder to the grille in the storage position.
12. Position the cylinder to the frame and install the
pin and the retainer pin to secure the lift cylinder in
the storage position.
Tip: When the pins are removed from the attachment arm, it
will be free to tilt down to the ground. Support the
attachment arm while the pins are being removed.
13. Remove the two retainer pins and pins and lower
the attachment arm fully.
14. Reinstall the pins and the retainer pins into the
attachment arm for storage.
