Polaris RANGER ETX 2015 - Standard Bolt Torque Specification; Metric Bolt Torque Specification

9926806 R03 - 2015 - 2016 RANGER ETX / 570 2-SEAT 2015 - 2016 RANGER 570 CREW Service Manual
© Copyright Polaris Industries Inc.
1.35
STANDARD BOLT TORQUE SPECIFICATION
BOLT SIZE
GRADE 2
FT-LB (NM)
GRADE 5
FT-LB (NM)
GRADE 8
FT-LB (NM)
1/4-20
5 (7) 8 (11) 12 (16)
1/4-28
6 (8) 10 (14) 14 (19)
5/16-18
11 (15) 17 (23) 25 (35)
5/16-24
12 (16) 19 (26) 29 (40)
3/8-16
20 (27) 30 (40) 45 (62)
3/8-24
23 (32) 35 (48) 50 (69)
7/16-14
30 (40) 50 (69) 70 (97)
7/16-20
35 (48) 55 (76) 80 (110)
1/2-13
50 (69) 75 (104) 110 (152)
1/2-20
55 (76) 90 (124) 120 (166)
METRIC BOLT TORQUE SPECIFICATION
BOLT
SIZE
GRADE
4.6 4.8 8.8 / 8.9 10.9 12.9
FT-LB (NM) DRY THREADS
M3
0.3 (0.5) 0.5 (0.7) 1 (1.3) 1.5 (2) 1.5 (2)
M4
0.8 (1.1) 1 (1.5) 2 (3) 3 (4.5) 4 (5)
M5
1.5 (2.5) 2 (3) 4.5 (6) 6.5 (9) 7.5 (10)
M6
3 (4) 4 (5.5) 7.5 (10) 11 (15) 13 (18)
M8
7 (9.5) 10 (13) 18 (25) 26 (35) 33 (45)
M10
14 (19) 18 (25) 37 (50) 55 (75) 63 (85)
M12
26 (35) 33 (45) 63 (85) 97 (130) 111 (150)
M14
37 (50) 55 (75) 103 (140) 151 (205) 177 (240)
M16
59 (80) 85 (115) 159 (215) 232 (315) 273 (370)
M18
81 (110) 118 (160) 225 (305) 321 (435) 376 (510)
GENERAL INFORMATION
1
