9
9926806 R03 - 2015 - 2016 RANGER ETX / 570 2-SEAT 2015 - 2016 RANGER 570 CREW Service Manual
© Copyright Polaris Industries Inc.
9.27
DISC REMOVAL / REPLACEMENT
1. Remove bolts
q
and disc
w
.
2. Clean mating surface of disc and hub
e
.
3. Install disc on hub.
4. Apply Loctite® 272 to new bolts, install and tighten to
specification.
TORQUE
Front Brake Disc Mounting Bolts:
18 ft-lbs (25 Nm)
BRAKE SYSTEM
