9.3
GENERAL INFORMATION
BRAKE SERVICE SPECIFICATIONS
FRONT BRAKE
ITEM
STANDARD SERVICE LIMIT
Front Brake Pad Thickness
0.298 ± .007" / 7.56 ± .178 mm 0.030" (.76 mm)
Front Brake Disc Thickness
0.158" (4.01 mm) 0.140" (3.56mm)
Front Brake Disc Runout
-
0.010" (.254mm)
REAR BRAKE
ITEM
STANDARD SERVICE LIMIT
Rear Brake Pad Thickness
0.298 ± .007"/ 7.56 ± .178 mm 0.030" (.76 mm)
Rear Brake Disc Thickness
0.188" (4.78 mm) 0.170" (4.32 mm)
Rear Brake Disc Runout
-
0.010" (.254 mm)
TORQUE SPECIFICATIONS
ITEM
TORQUE
Bleeder Screws
47 in-lbs (5 Nm)
Brake Disc Mounting Bolts
(Front)
18 ft-lbs (25 Nm)
Brake Disc Mounting Bolts
(Rear)
27 ft-lbs (36 Nm)
Brake Line Banjo Bolts 15 ft-lbs (20 Nm)
Brake Line Flare Fittings 14 ft-lbs (19 Nm)
Brake Switch
15 ft-lbs (20 Nm)
Caliper Mounting Bolts 46 ft-lbs (62 Nm)
Hub Nut (front) 90 ft-lbs (122 Nm)
Hub Nut (rear) 110 ft-lbs (150 Nm)
Master Cylinder Mount
Bolts
17 ft-lbs (23 Nm)
SPECIAL TOOLS
PART NUMBER TOOL DESCRIPTION
2870975
Mity Vac™ Pressure Test
Tool
Bosch Automotive Service Solutions: 1-800-345-2233
or http://polaris.service-solutions.com
BRAKE SYSTEM
