7.36
9926806 R03 - 2015 - 2016 RANGER ETX / 570 2-SEAT 2015 - 2016 RANGER 570 CREW Service Manual
© Copyright Polaris Industries Inc.
7. Install the wheel, washers
t
and wheel nuts
r
.
Torque wheel nuts to specification.
TORQUE
Steel Wheel Nuts:
36 ft-lbs (49 Nm)
Aluminum Wheel Nuts:
30 ft-lbs + 90º (41 Nm + 90º)
8. Carefully lower the vehicle. Torque the rear hub
castle nut to specification. Install a new cotter pin
q
.
TORQUE
Rear Hub Castle Nut:
110 ft-lbs (150 Nm)
FINAL DRIVE
