CLUTCH
6.6
PVT DISASSEMBLY, CONT.
7. Remove driven clutch retaining bolt and driven clutch.
Use puller if necessary.
8. Remove driven clutch offset spacers from the
transmission input shaft.
9. Bend back retainer tabs on three screws at the front of
the inner cover (where applicable). Remove screws
and retainer plate.
10. Remove inner cover retaining bolts at rear of cover.
11. Remove cover along with foam seal on back of cover or
shaft.
Driven Clutch Puller PN 2870913
Keep Spacers In Order
