ENGINE
3.1
TORQUE SPECIFICATIONS
ENGINE TORQUE SPECIFICATIONS
Fastener Size 325
ES32PFE
Ft. Lbs. (Nm)
Camshaft Chain Tensioner Lever 6mm 5-6.5 (7-9 Nm)
Camshaft Chain Tensioner 6mm 5-6.5 (7-9 Nm)
Camshaft Chain Tensioner Cap 11mm 14-19 (20-25 Nm)
Camshaft Sprocket 10mm 25-29 (34-40 Nm)
Carburetor Adaptor 8mm 12-14 (16-20 Nm)
Connecting Rod 8.5mm 29-33 (39-45 Nm)
Crankcase 8mm 14-15 (19-21 Nm)
Crankshaft Slotted Nut (Drive Sprocket) 28mm 35-51 (47-69 Nm)
Cylinder Base Bolts 6mm 5-7 (7-9 Nm)
Cylinder Head Bolts 10mm Refer to Engine
Assembly for torque pro-
cedure
Drive Clutch Bolt 7/16 - 20 40 (55 Nm)
Flywheel 16mm 58-72 (78-98 Nm)
Oil Hose Fittings 1/2 & 9/16 20 (27 Nm)
Oil Delivery Pipe 12mm 11-15 (15-21 Nm)
Oil Drain Bolt (Crankcase) 14mm 14-17 (19-23 Nm)
Oil Filter Pipe Fitting (Connector) 20mm 36-43 (49-59 Nm)
Oil Line Fitting 20 (27 Nm)
Oil Pump Cover 6mm 4-5 (5-7 Nm)
Oil Relief Valve Plug 14mm 14.5-16.5 (20-23 Nm)
Recoil Housing 6mm 5-6.5 (7-9 Nm)
Rocker Cover 6mm 7-8 (9-11 Nm)
Rocker Cover Block Plug 28mm 39-44 (53-59)
Rocker Adjuster Screw Lock Nut 6mm 6-7 (8-10 Nm)
Stator Plate 6mm 5-6.5 (7-9 Nm)
Starter Motor 6mm 5-6.5 (7-9 Nm)
Spark Plug 14mm 9-11 (12-15 Nm)
