SPECIFICATIONS
UTV 2x4 UTV 4x4 UTV 6x6
Gross Vehicle Weight 2500 lbs. (1135 kg) 2700 lbs. (1226 kg) 2900 lbs. (1317 kg)
Fuel Capacity 8.0 gal. (30 l) 8.0 gal. (30 l) 8.0 gal. (30 l)
Towing Capacity 1400 lbs. (636 kg) 1500 lbs. (681 kgs) 1500 lbs. (681 kgs)
Max. Cargo Box Load 850 lbs. (386 kg) 1000 lbs. (454 kg) 1000 lbs. (454 kgs)
Overall Length 113 in. (282 cm) 113 in. (282 cm) 120 in. (304.8 cm)
Overall Width (box) 60 in. (152.4 cm) 60 in. (152.4 cm) 60 in. (152.4 cm)
Overall Width (tires) 58 in. (147.3 cm) 58 in. (147.3 cm) 58 in. (147.3 cm)
Overall Height 74 in. (187.9 cm) 75 in. (190.5 cm) 75 in. (190.5 cm)
Wheelbase 76 in. (193 cm) 76 in. (193 cm) 90 in. (228.6 cm)
Ground Clearance 7.2 in. (183 mm) 7.2 in. (183 mm) 7.2 in. (183 mm)
Dry Weight 1196 lbs. (543 kg) 1263 lbs. (573 kg) 1410 lbs. (640 kg)
Cargo Box
(LxWxH)
58x46x10in.
(147x117x25.4cm)
58x46x10in.
(147x117x25.4cm)
58x46x10in.
(147x117x25.4cm)
Min. T urning Radius 132 in. (335.3 cm) 132 in. (335.3 cm) 186 in. (472.4 cm)
Engine Oil Capacity 2qts.(2.1l) 2qts.(2.1l) 2qts.(2.1l)
Coolant Capacity 2.25 qts. (2.4 l) 2.25 qts. (2.4 l) 2.25 qts. (2.4 l)
Engine 4 valve 4 stroke
single cylinder with
counter balance
4 valve 4 stroke
single cylinder with
counter balance
4 valve 4 stroke
single cylinder with
counter balance
Displacement 425 cc 499 cc 499 cc
Bore x Stroke 87.9 x 70 92x75 92x75
Pilot Jet 42.5 42.5 42.5
Main Jet 135 142.5 142.5
Needle Jet P-6 (829) P-6 (829) P-6 (829)
Jet Needle 4LC38 -3 4MB32-3 4MB32-3
Air Screw 21/4 21/2 21/2
Alternator Output 250 W 250 W 250 W
Compression Ratio 9.2 10.2:1 10.2:1
Starting System Electric Electric Electric
Carburetor 34 mm
CV Mikuni
34 mm
CV Mikuni
34 mm
CV Mikuni
Ignition System CDI CDI CDI
Ignition Timing 30_ @ 5000 rpm 30_ @ 5000 rpm 30_ @ 5000 rpm
Spark Plug NGK BKR5E NGK BKR5E NGK BKR5E
