Polyaire airtouch - Page 57

57
R
S
4
8
5
A
+
B
-
H
o
m
e
K
it
S/A2
E/M T Z1 Z2 Z3 Z4
Z8 Z7 Z6 Z5 B2 B1
L N
RS485
A+ B-
S1
S2
S/A1-2: Supply Air Sensors
E/M: Extension Module T: Touchscreen
Z1...Z8: Zone Dampers L and N: 24V AC Power Supply
B1 and B2: Bypass Dampers
HomeKit: HomeKit Module
RS485: AC Gateway
AC Gateway
F3 F4
F3 F4
AirTouch 4
S/A1
657211 (RS485 Cable) from Polyaire
(Provided with the gateway)
Two stripped wires
(field prepared)
AC Indoor PCB
Gateway Address Setting
S1
Gateway Address
1000
1
0100 2 1100 3 0010 4
657229
Note:
1. 0-Off, 1-On, x-On
2. Samsung wall controller cannot be with the gateway at the same time
NASA (
657229
)
Wiring Diagram
Wiring Diagrams contd.
