Administrator’s Guide for the VSX Series
3 - 24
Configuring the Serial V.35/RS-449/RS-530 Network Interface
If you have a VSX 7000, VSX 7000s, VSX 7000e, or VSX 8000 system, the
optional serial V.35/RS-449/RS-530 network interface allows you to connect
to data communications equipment using a V.35, RS-449, or RS-530 serial
interface.
To configure the V.35/RS-449/RS-530 network interface settings:
1. Go to System > Admin Settings > Network > V.35/RS-449/RS-530.
2. Configure these settings:
3. Select and configure these settings:
Setting Description
Enable
V.35/RS-449/RS-530
Allows the system to connect to a terminal adapter using
a V.35, RS-449, or RS-530 connection.
V.35 Ports Used Specifies whether one or two lines are connected.
RS-366 Dialing Allows users to dial calls from this system.
Clear this setting if this is a dedicated connection or if
another device is used for dialing calls.
Area Code
Port 1
Port 2
Specifies the area code and number(s) that other sites
dial to reach this system.
If this is a dedicated connection, leave these fields blank.
Setting Description
Prefix Lets you specify the dialing prefix required to reach an
outside line.
Calling Profile Lets you specify what data communications equipment is
connected to the network interface. The system
automatically displays the default prefixes, suffixes, and
calling speeds required by that device.
If your device is not listed, select Custom.
Speed Lets you define the prefixes or suffixes to use for each
speed used in a Custom Calling Profile. For information
about required prefixes and suffixes, see the
documentation that came with the device.
If you choose a predefined Calling Profile, this
information is supplied for you.
