Polygroup RP350-S - Rotor Replacement Instructions

2. To depressurize the Filter Pump system, vent the filter pump by twisting the Vent Screw 8 counter-clockwise.
3. Loosen the Hose Clamps 6 at the filter pump inlet and outlet. Detach both Hoses 5 from the filter pump.
4. Turn the filter pump up-side-down. Remove the Motor Assembly Washer and Screw Set 21 .
5. Remove the Motor Assembly 13 from the Canister 12 . .
ROTOR REPLACEMENT INSTRUCTION
12
12
13
13
21
1. Unplug the Power Filter Pump. Remove the Flow Diverter 3 ,Suction Fitting Screen 2 and Suction Fitting Base 1 from the Return Fitting and Suction Fitting
and flow plug with Plug 4 .
15
OWNER’S MANUAL
