POMCube iCAN NetZero - BCMS Module Status and SOC

14
8
RS485-1 LINK2
Communicate with other BCMS module.
9
CAN-LINK1
Communicate with EMS module.
10
STATUS
Indicate BCMS module status:
Blinking blue: Boot up in progress;
Blinking green: Self-inspecting;
Solid green: Working normally;
Solid pink: Alarming
Solid red: In device protection or troubles.
11
SOC
Indicate real time battery capacity: Each light
represents 25% capacity. The lights blink in
sequence under system charging and
discharging.
12
ADD
The communication address of BCMS
module.
13
Dry Contact
Reserved. Four output and two input.
14
LINK
Communicate with battery module.
15
D+
DC bus positive (+).
16
D-
DC bus negative (-).
17
DC-12V
DC12V power supply output.
