PONSSE H73 - Electrical Diagram: IPS System

Service training
000
28022000
3.3
Electric diagram (IPS)
Location number of pin connector box
Directional valve
solenoids+diodes
Saw rotation
Saw feed
Slow forward
Slow reverse
Rollers open
Front knives open
Fast forward
Fast reverse
black
black
black
brown
brown
blue
brown
blue
Saw limit A
Saw limit B
black
brown
blue
Tilt limit
Feed current length sensor
red
yellow
green
blue
Length sensor
Diameter
sensor
blue
yellow
Tilt up
Rear knives open
Rear knives open extra pressure
Color 1 (blue)
Color 2 (red)
Urea valve
Rotator right
Rotator left
Front knives open extra pressure
GND
