G-2108/G-3106 User’s Manual Chapter 2: Setup and Use
7
Figure 3
1. Printhead Module
5. Reflective Sensor
9. Ribbon Supply Spindle
2. Printhead Bracket
6. TPH Release Lever
10. Media loading area
3. Printhead
7. Media Guide
11. Ribbon Adjusting Wheel
4. Transmissive Sensor
8. Ribbon Loading Knob
12. Platen Roller
2
1
3
4
12
6
7
8
9
10
11
5
