G-2108/G-3106 User’s Manual Chapter 1: Introduction
3
Chapter 1: Introduction
Printer Specifications
Model
G-2108
G-3106
Printing Method
Direct Thermal & Thermal Transfer
Printing Resolution
203 dpi (8 dots/mm)
300 dpi (11.8 dots/mm)
Max Printing Speed
6ips (152.4 mm/s)
4ips (101.6 mm/s)
Max Printing Width
4.25″ (108 mm)
4.17″ (106 mm)
Max Printing Length
315″ (8000 mm)
157″ (4000 mm)
Memory
8 MB FLASH ROM, 16 MB SDRAM
Media
Roll-feed, die-cut, continuous, fan-fold, tags, tickets in plain paper or thermal paper
Width: 4.3″ (110 mm) max., 0.98″ (25 mm) min., or with optional adapter .31″ (8 mm)
min.
Supply roll: OD 6″ (152 mm) max., ID 1″ (25.4 mm) min.
Thickness: 0.003″～0.008″ (0.08～0.20 mm), including liner
Ribbon
Wax, Wax/Resin, Resin
Ribbon roll: OD 2.75″ (70 mm) max., ID 1″ (25.4 mm) core
Max width: 4.3″ (110 mm); Max length: 984.25’ (300 m). Ink side: Out
Fonts
Five built-in ASCII fonts; Optional multiple language fonts
Bar Code Types
1D Barcode: Code 39, Code 93, Code 128/subset A,B,C, Codabar, Interleave 2 of 5, UPC
A/E 2 and 5 add-on, EAN-13/8/128, UCC-128.
2D Barcode : MaxiCode, PDF417, Data Matrix, QR.
Media Sensor
Reflective (Adjustable) / Transmissive
Interfaces
RS-232 Serial, USB 2.0, 10/100M Ethernet.
Power Rating
24 VDC, 2.5 A
Weight
7.72lbs (3.5 kgs)
Dimensions
W 10.07” x D 12.95” x H 7.8” (W 256 x D 329 x H 200 mm)
Operation Environment
Temperature: 32 F ~ +104 F (0 C ~ 40 C)
Relative humidity: 5% - 85% non condensing
Storage Environment
Temperature: -40 F ~ +140 F (-40 C ~ 60 C)
Relative humidity: 5% - 85% non condensing
Optional Items
External Rewinder, External Media Stand, Rotary Cutter, Media Guide Adapter, and
Centronics Parallel.
