2.1.2 Internal View
Figure 2-2 shows the detailed structure of the printer.
Figure 2-2 Internal View
Table 2-2 Internal View Description
Number
Description
1
Handle
2
Printhead Assembly
3
Platen Roller
4
Media Guide
5
Media Guide Rod
6
Media Compartment
