iQ200 User’s Manual Chapter 3: Operations and Settings
23
3.1.4 DIP Switches
The DIP Switch is located on the back of the printer, as shown in Figure 3-2.
Figure 3-2 DIP Switch
Table 3-3 DIP Switch Description
Position
Corresponding Functions
1
Set printing mode
ON: Direct Thermal
OFF: Thermal Transfer
2
Set Tear-off Mode
ON: Tear-off Mode enabled
OFF: Tear-off Mode disabled
3
Set Cutter Mode (Only available on models with Cutter installed)
ON: Cutter Mode enabled
OFF: Cutter Mode disabled
4
Set Peeler Mode (Only available on models with Peeler installed)
ON: Peeler Mode enabled
OFF: Peeler Mode disabled
5
Set the media sensor type
ON: Transmissive
OFF: Reflective
6
Set DHCP (Dynamic Host Configuration Protocol)
ON: Enabled
OFF: Disabled
7&8
Set serial BAUD-RATE
BAUD-RATE for each combination:
7 OFF & 8 OFF: 9600
7 ON & 8 OFF: 19200
