iQ200 User’s Manual Chapter 2: Setup and Use
19
Figure 2-20 End-fixing Tape Position
The position of the
tape should be made
known to user to
avoid positioning
Media Sensors over
the tape area.
The position of the
tape should be made
known to user to
avoid positioning
Media Sensors over
the tape area.
Hole
Media gap
Black Mark
Black Mark
Tape
Tape
Tape
Tape
The tape shall avoid
covering the hole
The tape shall avoid
covering the black mark
