7. Scan Mode Image (OBM-U240/U241/U310/U311/U550L/X241/X310)
OBM-U240/U241/U310/U311/U550L/X241/X310)
4K/QFHD Mode
When the 4096x2160 signal is fed, if you select Zero Scan using [Scan] buon on the front panel, the picture is
scaled to be displayed on the panel of 3840x2048 resoluon with maintaining 1.89:1 rao.
If you press [Scan] buon once more, [1:1 Scan] mode is selected.
To see the image on the right-end and the le-end area, the locaon of the image can be moved by rotang
the [SELECT/VOLUME] knob.
**Note -When QFHD/DCI 4K signal is fed, [Aspect] buon is not acvated.
The LCD panel resoluon of OBM-U240/U550L is QFHD(16:9) 3840x2160, so if the input signal is 3840x2160,
1:1 mapping is supported. If the input signal is DCI 4K(1.89:1) 4096x2160, 1:1 mapping is not supported.
3840 x 2160
4096 x 2160
[Le]
[Center]
[Right]
3840 x 2160
4096 x 2160
3840 x 2028
3840 x 2160
[Zero Scan]
[1:1 Scan]
Panel
Input image
3840 x 2160
4096 x 2160
