9. Connecting the SDI Signals
Single Link 12G/6G/3G/HD-SDI, Dual-Link 3G-SDI, and Quad-Link 3G-SDI signals can be input to the SDI IN
connectors of this monitor.
Up to 2-channel Single Link 12-SDI signals, up to 4-channel 3G/HD-SDI signals, 1-channel Dual-Link 3G-SDI or
1-channel Quad-Link 3G-SDI signals can be input. Use the appropriate input connectors depending on the
input signal, referring to the tables below.
Single-Link 12G –SDI Signal
Dual-Link 3G –SDI Signal
* 2-sample interleave division signals
Quad-Link 3G/HD –SDI Signal
* 2-sample interleave division signals
* Square division signals
Image of Square division signals
Sub-Image1
(upper-left screen)
Sub-Image2
(upper-right screen)
Sub-Image3
(lower-left screen)
Sub-Image4
(lower-right screen)
Connector Input signal
12G SDI -1 12G SDI
12G SDI 12G SDI -2
Connector
Input signal
12G SDI -1 3G SDI Link1
3G SDI Link2 12G SDI -2
Connector
Input signal
12G SDI -1 3G SDI Link1
3G SDI Link2
3G SDI Link3
3G SDI Link4
12G SDI -2
3G SDI -3
3G SDI -4
Connector
Input signal
12G SDI -1 Sub-Image 1 (upper-le screen)
Sub-Image 2 (upper-right screen)
Sub-Image 3 (lower-le screen)
Sub-Image 4 (lower-right screen)
12G SDI -2
3G SDI -3
3G SDI -4
