PRK-5000 Operation Manual
- 24 -
(4) Displaying of stored Image and Data
z Press DISP. button in observation display. Images stored in memory will be
displayed.
[Menu Display]
z Press AUTO or DISP. button in menu display to select the image to be magnified
with the cursor.
z Press SIZE button. Image will be display in standard size or double size.
[Standard Size Display / Double Size Display]
Serial number – Sub number
Date
Time
Right side eye [Mode]
Press PRT switch to return to
Observe mode.
Press ILLUM. switch to
return to
Measurement mode.
Press switch to move the cursor.
Press SIZE switch to magnify the
selected image to standard size.
MODE switch is invalid
Data of the image
selected with the curso
r
Press MODE switch to
return to Menu Display.
Press SIZE switch to change
selected image size.
Curso
r
Images of right side eye Images of left side eye
