PRK-5000 Operation Manual
- 37 -
(5) Attach the ejector to the printer.
NOTES:
Attach the ejector to the printer such that the shaft of the
ejector snaps into the printer to secure tight contact
between the paper and the printer.
(6) Attach the cover to the printer.
7.2.2 Chin Rest Paper
(1) Pull out the two pins on the chin rest.
(2) Insert the pins into the holes on the chin rest paper. More than 50 sheets of paper can
be attached.
(3) Insert the pins straight into the holes on the chin rest.
7.2.3 Fuses
(1) Turn off the power.
(2) Remove the power cord from the electrical inlet
(3) Insert flatblade screwdriver into notches in the fuseholder cover. Then turn the
screwdriver countclockwise
(4) Replace the fuses and reset the fuseholder cover in its original positions
Fuse rating: T3.15A 250V
7.3 Cleaning
(1) Basically, keep this instrument clean. Don’t use volatile object, thinner or benzene, etc.
(2) Polish each part with a dry cloth containing detergent solution.
